socket am4
cpu
amd socket am4 for amd ryzen 5000 series – 5000 g – series – 4000 g – series – 3000 series desktop processors*
* refer to www.asus.com for cpu support list.
chipset
amd b550 chipset
memoria
2 x dimm slots – max. 64gb – ddr4 5100(oc) – 4866(oc) – 4600(oc) – 4466(oc) – 4400(oc) – 4333(oc) – 4266(oc) – 4200(oc) – 4133(oc) – 4000(oc) – 3866(oc) – 3733(oc) – 3600(oc) – 3466(oc) – 3400(oc) – 3333
(oc) – 3200 – 3000 – 2933 – 2800 – 2666 – 2400 – 2133 – un – buffered memory*
dual channel memory architecture
* ecc memory (ecc mode) support varies by cpu.
* supported memory types – data rate (speed) – and number of dram modules vary depending on the cpu and memory configuratión – for more informatión please refer to cpu – memory support list under the support tab of
product informatión site or visit https: – – www.asus.com – support – .
gráficos
1 x displayport**
1 x hdmi port***
* graphics specificatións may vary between cpu types. please refer to amd cpu specificatións.
** supports max. 4k@60hz as specified in displayport 1.4.
*** supports 4k@60hz as specified in hdmi 2.1.
ranuras de expansión
amd ryzen 5000 series – 3000 series desktop processors
1 x pcie 4.0 x16 slot (supports x16 mode)
amd ryzen 5000 g – series – 4000 g – series desktop processors
1 x pcie 3.0 x16 slot (supports x16 mode)
amd b550 chipset
1 x pcie 3.0 x1 slot
* please check the pcie bifurcatión table on the support site (https: – – www.asus.com – support – faq – 1037507 – ).
– to ensure compatibility of the device installed – please refer to https: – – www.asus.com – support – for the list of supported peripherals.
almacenamiento
total supports 2 x m.2 slots and 4 x sata 6gb – s ports*
amd ryzen 5000 series – 3000 series desktop processors
m.2_1 slot (key m) – type 2242 – 2260 – 2280 (supports pcie 4.0 x4 & sata modes)
amd ryzen 5000 g – series – 4000 g – series desktop processors
m.2_1 slot (key m) – type 2242 – 2260 – 2280 (supports pcie 3.0 x4 & sata modes)
amd b550 chipset
m.2_2 slot (key m) – type 2242 – 2260 – 2280 – 22110 (supports pcie 3.0 x4 & sata modes)
4 x sata 6gb – s ports
* amd raidxpert2 technology supports both pcie raid 0 – 1 – 10 and sata raid 0 – 1 – 10.
ethernet
1 x realtek 1gb ethernet
usb
rear usb (total 6 ports)
4 x usb 3.2 gen 1 (5g) ports (4 x type – a)
2 x usb 2.0 ports (2 x type – a)
front usb (total 7 ports)
1 x usb 3.2 gen 1 (5g) connector (supports usb type – c)
1 x usb 3.2 gen 1 (5g) header supports 2 additiónal usb 3.2 gen 1 ports
2 x usb 2.0 headers support 4 additiónal usb 2.0 ports
audio
realtek 7.1 surround sound high definitión audio codec*
– supports: jack – detectión – multi – streaming – front panel jack – retasking
– supports up to 24 – bit – 192 khz playback
audio features
– audio shielding
– premium audio capacitors
– dedicated audio pcb layers
* a chassis with an hd audio module in the front panel is required to support 7.1 surround sound audio output.
puertos de e – s del panel posterior
4 x usb 3.2 gen 1 (5g) ports (4 x type – a)
2 x usb 2.0 ports (2 x type – a)
1 x displayport
1 x hdmi port
1 x realtek 1gb ethernet port
3 x audio jacks
1 x ps – 2 keyboard – mouse combo port
conectores de e – s internos
fan and cooling related
1 x 4 – pin cpu fan header
2 x 4 – pin chassis fan headers
power related
1 x 24 – pin main power connector
1 x 8 – pin +12v power connector
storage related
2 x m.2 slots (key m)
4 x sata 6gb – s ports
usb
1 x usb 3.2 gen 1 (5g) connector (supports usb type – c )
1 x usb 3.2 gen 1 (5g) header supports 2 additiónal usb 3.2 gen 1 ports
2 x usb 2.0 headers support 4 additiónal usb 2.0 ports
miscellaneous
3 x addressable gen 2 headers
1 x clear cmos header
1 x com port header
1 x front panel audio header (aafp)
1 x s – pdif out header
1 x speaker header
1 x spi tpm header (14 – 1 pin)
1 x 10 – 1 pin system panel header
características especiales
asus 5x protection iii
– digi+ vrm
– languard
– overvoltage protectión
– safeslot core
– stainless – steel back i – o
asus q – design
– q – dimm
– q – led core
– q – slot
asus thermal solutión
– aluminum heatsink design
aura sync
– addressable gen 2 headers
funciónes de software
asus exclusive software
armoury crate
– aura creator
– aura sync
ai suite 3
– performance and power saving utility
turbov evo
epu
digi+ vrm
fan xpert 2+
– ez update
asus cpu – z
nortón 360 deluxe (60 days free trial)
winrar
uefi bios
asus ez diy
– asus crashfree bios 3
– asus ez flash 3
– asus uefi bios ez mode
bios
128 mb flash rom – uefi ami bios
manejabilidad
wol by pme – pxe
accesorios
cables
2 x sata 6gb – s cables
miscellaneous
1 x i – o shield
1 x screw package for m.2 ssd
documentatión
1 x user guide
sistema operativo
windows 11 – windows 10 64 – bit
factor de forma
micro – atx form factor
9.6 inch x 8.7 inch ( 24.4 cm x 22.1 cm )
