Capacity 10 – 200kva
main input
input voltage pulgadas380v – 400v – 415v(line to line)220v – 230v – 240v(line to neutral) pulgadas
input frequency 50 – 60hz
power factor >0.99
input voltage window – 40%~+25%
frequency window 40 – 70hz
battery
battery voltage ±240vdc
charger power 20%*power
charger voltage precisión 1%
bypass
bypass voltage pulgadas380v – 400v – 415v – three phase220v – 230v – 240v – one phase pulgadas
bypass voltage window – 20% – +15% – full load – settable
bypass overload capabiltiy 125% – long time operatión
125%< load <130% - last for more than 1 hour
130%
output
output voltage pulgadas380v – 400v – 415v – three phase220v – 230v – 240v – one phase pulgadas
voltage precisión ±0.5% (balance load) -±1% (unbalance load)
voltage thd(total harmonic distortión) thd<1%(linear load) -thd<5%(nonlinear load) power factor 0.8 phase tolerance 120°±0.5° (balance and unalance load) crest factor 3:1 overload capabiltiy 105% -long time operatión 110% – transfer to bypass after 1hour 125% – transfer to bypass after 10 minutes 150% – transfer to bypass after 1 minute >150% – transfer to bypass after 200ms
system
system efficiency normal mode: 95%
eco mode: 99%
battery mode efficiency 95%
display lcd+led – touch screen and keyboard
ip class ip20
interface (communicatión ports ) rs232 -rs485 -dry contacts -snmp card -epo -generator
interface
installatión – connectión top or bottom cable connectión
operatión temperature 0 – 40
storage temperature – 25~70
relative humidity 0 – 95% (non – comdensing)
noise(db) <55db
weight(kg) 6 – module cabinet rm060 – 10 – rm090 – 15 – rm120 – 20
150kg
10 – module cabinet rm100 – 10 – rm150 – 15 – rm200 – 20
180kg
pm10 10kva: 20kg
pm15 15kva: 21kg
pm20 20kva: 22kg
dimensión(w*d*h)(mm) 6 – module cabinet 600*900*1600
10 – module cabinet 600*900*2000
module 400*600*133 (10kva – 15kva – 20kva)
