Main input
input voltage 380v – 400v – 415v(line to line) – 50 – 60hz
input connectión 3ph+n+pe
power factor >0.99
input voltage window +25%~ – 20% – full load
– 20%~ – 40% – power derating between 100% to 70%
frequency window 40 – 70hz
bypass input
bypass voltage 380v – 400v – 415v
bypass voltage window +15% – – 20% – full load
frequency window ±5hz
battery
battery voltage ±240vdc
charger power 20%*power
charger voltage precisión 1%
output
voltage precisión ±0.5% (balance load) -1% (unbalance load)
output voltage transient 5%(0~100% load step)
voltage thd(total harmonic distortión) thd<1%(linear load) -thd<5%(nonlinear
load)
power factor 0.8
frequency tracking range 50 – 60hz±3hz – adjustable
frequency precisión (free running) ±0.02%
phase tolerance 120°±0.5° (balance and unalance load)
voltage unbalance degree (100% unbalance load) ±1%
frequency tracking speed 0.5hz – s to 5hz – s – adjustable
crest factor 3:1
overload capabiltiy 102% long time operatión
110% – transfer to bypass after 1hour
125% – transfer to bypass after 10 minutes
150% – transfer to bypass after 1 minute
>150% – transfer to bypass after 200ms
bypass overload capability 125% – long time operatión
125%< load <130% - last for more than 1 hour
130%
system
system efficiency normal mode: 95%
eco mode: 99%
battery mode efficiency 95%
battery configuratión 12v – 40pcs (36~44pcs acceptable)
display lcd+led – keyboard
emi iec62040 – 2
ems iec61000 – 4 – 2(esd)
iec61000 – 4 – 3(rs)
iec61000 – 4 – 4 (eft)
iec61000 – 4 – 5 (surge)
insulatión resistance >2m (500vdc)
dielectric strengh (input -output to pe)2820vdc – leakage current lower than 3.5ma –
no flashover in 1 minute
surge protectión comply with iec60664 – 1 class iv – endure surge of 1.2 – 50us +
8 – 20us higher than 6kv – 3ka
ip class ip20
interface (communicatión ports ) rs232 -rs485 -dry contacts -snmp
card -epo -generator interface
installatión – connectión top or bottom cable connectión
operatión temperature 0 – 40
relative humidity 0 – 90% (non – comdensing)
noise(db) <55db
